ADO folding guide
Choosing a folding electric bike for commuting, a caravan or the car boot? The ADO Air 20 Ultra V2026 combines a 50Nm automatic three-speed drive with a 37V 10Ah CAN battery. Its folded size is 885 × 510 × 670 mm (L × W × H). Compare it with the Air 20 Pro and Carbon Pro below, then check the Ultra product page for live price and availability.
Quick chooser
Ultra uses three automatic speeds; Pro and Carbon Pro use two. The motor handles gear changes while torque-sensor assistance responds to pedalling effort. Their carbon belts need no chain oil, keeping handling cleaner and reducing routine drivetrain maintenance.
All three offer NFC power-on and ADO app ride recording with riding statistics. Carbon Pro also has built-in GPS tracking. Compare folded size, tyre width, suspension and the qualified weights below to choose the right bike for your trip and storage space.
ADO in motion
Watch the folding range in use, then use the image strip to compare the everyday ADO details: compact storage, commuting setup and the lighter Carbon Pro option.
ADO folding range
The automatic three-speed option for commuting and travel. Check its folded footprint and your lifting setup before choosing.
$3,449.00
The automatic two-speed option with a shorter, narrower folded footprint than Ultra.
$2,899.00
A carbon-frame alternative. Its weight includes the rack and mudguards, unlike the Ultra and Pro net figures.
$3,949.00
Compare
Shared specifications span all three models. Scroll across on smaller screens to compare the differences.
| What to compare | Air 20 Ultra V2026 | Air 20 Pro V2026 | Air Carbon Pro |
|---|---|---|---|
| Battery | 37V 10Ah battery. | ||
| Shared commuting equipment | Lights, mudguards and rear rack. Individual light output and other model-specific equipment remain separate below. | ||
| Rider height | 150–190cm for all three models. Check individual fit and riding comfort. | ||
| Maximum bike load | 120kg for all three models. Rear-rack load counts within this total, not in addition to it. | ||
| Assisted range | Up to 100km assisted. Distance varies with rider/cargo load, assistance level, terrain, wind and tyre pressure; allow a reserve. Optional range extenders are not included in this common figure. | ||
| Charging | 4–6 hours for all three models. | ||
| Display | 2.4-inch colour display with NFC. | ||
| Rear-rack compatibility and limit | MIK-compatible rear rack, up to 25kg. Rack load counts within the bike limit; mounting compatibility is not child-seat approval. | ||
| Motor and gears | 250W, 50Nm; automatic 3-speed | 250W, 50Nm; automatic 2-speed | 250W; automatic 2-speed |
| Folded L × W × H | 885 × 510 × 670 mm | 850 × 480 × 670 mm | 870 × 480 × 660 mm |
| Qualified bike weight | ADO lists 20+kg net, excluding rear rack and mudguards. Battery inclusion is unspecified. | ADO lists 19+kg net, excluding rear rack and mudguards. Battery inclusion is unspecified. | 16.2kg including mudguards and rear rack. Battery inclusion is unspecified. |
| Tyres | 20 × 2.0 inches | 20 × 1.95 inches | 20 × 1.75 inches |
| Frame / lighting / accessory differences | Built-in 25lux headlight; AQS 2.0 support | 30lux headlight; AQS 2.0 support | Carbon frame and fork; built-in 25lux headlight; AQS 2.0 support |
Up to 100km is an assisted-range maximum, not a guarantee. Rider and cargo weight, assistance level, hills, wind and tyre pressure affect distance. Allow a reserve and plan charging stops for longer days away.
Check boot lip height, door width, interior depth and clearance to turn the folded bike. Allow space to secure it without loading fragile parts. Ultra/Pro weights exclude the rack and mudguards; Carbon’s includes them, so these are not identically equipped lifting weights.
FAQ
Do not judge lifting by the word “folding”. Ultra is listed at 20+kg net excluding rear rack and mudguards; battery inclusion is not stated. The equipped bike and your loading height determine the real task. Measure the opening, then try lifting and turning the actual bike safely before buying.
Both V2026 models have 37V 10Ah CAN batteries and 250W, 50Nm drives. Ultra has automatic three-speed gearing and 20 × 2.0-inch tyres; Pro has automatic two-speed gearing and 20 × 1.95-inch tyres. Pro folds to 850 × 480 × 670 mm versus Ultra’s 885 × 510 × 670 mm. Compare the gearing you prefer and the space you actually have.
No. Ultra’s 20+kg and Pro’s 19+kg net figures exclude rear rack and mudguards. Carbon Pro’s 16.2kg figure includes those items. Battery inclusion is not specified for these quoted figures. Keep the “+” qualifier and compare the bikes with the equipment you will actually carry.
Use the L × W × H measurements above as a starting point. Check the opening, hinges, wheel arches and the clearance needed to manoeuvre the bike, not only the final resting space. A test fit is more useful than assuming a nominally large boot will work.
Yes. Air 20 Ultra, Air 20 Pro and Air Carbon Pro each use a 37V 10Ah battery. The common range figure is up to 100km assisted; optional range extenders are not included.
Yes. The current ADO range has MIK-compatible rear racks. Ultra, Pro and Carbon Pro racks are rated up to 25kg; the separate One Ultra rack is rated up to 60kg. MIK compatibility does not make those load limits interchangeable.
Choose accessories for the exact rack and mounting system. MIK compatibility alone does not establish child-seat suitability or mean accessories are included; observe both rack and bike load limits. Ultra, Pro and Carbon Pro support AQS 2.0; choose the correct accessory and mounting system for the fitted rack.
Need a hand?
Measure your boot or caravan storage opening and the space inside. Bring those measurements to a Gold Coast test ride, and try lifting the equipped bike to your actual loading height. Explore the Ultra, Pro and Carbon Pro product pages for current prices and availability.
